Lighting in motion · Poll Residence (E-101 & E-102)

Scenes

Ready.

Light

Sun 14:30

Cutaway

Height 8'-0"

Lutron finish

Source drawings

E-101 First floor plan E-101 Partial cellar E-102 Second floor plan Complete permit drawing PDF

Raise / Lower Target

The Command Path

Choose a scene or press a keypad button.

Phone & Outage Simulator

Connection mode Home Internet available Wired Home LAN available Home Wi-Fi / AP available Processor powered

Lutron app · simulation

My home

Local app via Wi-Fi and LAN. Home internet is not required for this local path.

Astronomical schedule

Outdoor on time Use astronomical sunset Outdoor off time

Assign the buttons

Choose a scene or an individual circuit for each button at the selected station. Hybrid stations show two buttons.

Three ways to use a button

Scene: Evening sets several circuits to different levels.

Zone: Kitchen group sets several selected circuits together.

Single load: Toggle one lighting circuit.

These are examples for homeowner discussion, not approved programming. A two-button hybrid still has only one wired output.

Assign actual fixture groups to concealed dimmers

No concealed-output assignment is treated as confirmed on the permit drawings. The source load schedule leaves the 14 concealed output identities unresolved. Below, you can review and bind the 19 traced groups: 18 smart-dimmer candidates + 1 local door-jamb switch (upper-wic224) to the Mudroom M01–M08 and Upstairs U01–U06 dimmers.

Dimmer output Group traced on drawing

The drawing identifies fixture groups without establishing which concealed output will serve it. Choose each group explicitly.

Output	Proposed Fixture Group	Anchors	Status
M01	Altered Kitchen 111 island pair	2 fixtures	Proposed candidate
M02	Altered Kitchen 111 recessed downlights	10 fixtures	Proposed candidate
M03	Altered Kitchen 111 three L2 surface fixtures	3 fixtures	Proposed candidate
M04	Altered Kitchen 111 south under-cabinet strips	2 fixtures	Proposed candidate
M05	Altered Kitchen 111 breakfast table fixture	1 fixture	Proposed candidate
M06	New Family Room 112 recessed downlights	4 fixtures	Proposed candidate
M07	New Family Room 112 center fixture	1 fixture	Proposed candidate
M08	New Mudroom 113 ceiling fixture chain	4 fixtures	Proposed candidate
U01	New Bedroom #3 222 center fixture	1 fixture	Proposed candidate
U02	New Dressing 226 ceiling fixture pair	2 fixtures	Proposed candidate
U03	New Dressing 226 recessed downlights	6 fixtures	Proposed candidate
U04	New Vestibule 223 ceiling fixture	1 fixture	Proposed candidate
U05	Altered Hallways 209 / 228 ceiling group	3 fixtures	Proposed candidate
U06	Altered Hallway 205 / stair ceiling group	3 fixtures	Proposed candidate
O01	Exterior pool-house flood/tree circuit (Hybrid H12A)	Off-plan load	Dedicated switch-leg
O02	Exterior architectural tree lighting (Hybrid H12B)	Off-plan load	Dedicated switch-leg

Select an output above to adjust assignments or synchronize with the 3D fixture illumination model.

All 16 outputs · names and brightness

Light follows the scene

All off

Scene controls are in Advanced, keeping one synchronized set of preset buttons.

Each glowing symbol represents one lighting circuit. Output names and brightness levels are editable below.

Edit circuit names and brightness

Processor, controls, AP placement & 3D RF distances

Verifies Lutron RadioRA 3 Type X RF distance rules: minimum 5.0 ft clearance from Wi-Fi Access Points, maximum 25.0 ft to first two Type X neighbors, and 75.0 ft maximum radius from assigned processor.

Device Show 3D RF range rings Explore second processor (P2)

From	To Device / Node	3D Distance	Lutron Rule	Compliance Status

Calculations use true 3D Euclidean spatial coordinates accounting for floor slab elevations and ceiling heights.

Electrician wiring, installation & requirements

INSTALLATION COORDINATION · 21 OCTOBER 2026

Separate the commands from the load wiring.

The proposed system uses 14 concealed dimmers (RRST-PRO-N), 10 powered keypads (RRST-W3RL), and two indoor hybrid keypads (RRST-HN2B) serving outdoor lighting circuits. Keep original fixture groupings; reconcile each relocated output with approved drawings before rough-in.

These are coordination schematics, not an issued construction wiring plan. The electrician must confirm circuit identity, supply and neutral, conductor sizes, box fill, grounding, fixture compatibility and cable reuse. Isolate power at the breaker before wiring.

PRO
RRST-PRO-N

14 × hidden PRO dimmers

Keypad
RRST-W3RL

10 × keypads w/ Raise-Lower

Hybrid
RRST-HN2B

2 × hybrids · Outdoor loads

Proc
RR-PROC3-CW

1 planned · 2nd conditional

MANUFACTURER SPECIFICATION · LUTRON SUNNATA PRO (ST-PRO-N / RRST-PRO-N)

Official Installation Documentation & Phase Selection

Per official Lutron RadioRA 3 installation guidelines, the RRST-PRO-N is a neutral-required, phase-selectable architectural dimmer. Review the complete manufacturer installation sheets and terminal wiring details:

↗ Lutron Sunnata ST-PRO-N Support & Wiring Diagrams ↗ Lutron Installation Guide PDF (0302061)

Phase Selection: Default is Reverse-Phase (ELV / Trailing-Edge) for all dimmable LED downlights and electronic drivers. If controlling magnetic low-voltage (MLV) transformers, configure to Forward-Phase (Leading-Edge) via the front-accessible service switch (FASS).
Companion Dimmer (ST-RD / RRST-RD) Traveler: Connect blue terminal ONLY when multi-location companion dimming is present. In all single-pole closet banks (Mudroom & Mechanical Closet 225), the blue screw terminal must remain tightened down and unused.

Single-location PRO wiring: tighten the unused blue traveler screw. Do not connect to neutral, ground, or conductor.

Hybrid wiring is single-pole indoor only. Flying leads: black (hot), red (load), white (neutral), green (ground).

Multi-Gang Wattage Derating Rules (NEC & Lutron)

Device Model	Connected Load Type	Alone (1-Gang)	End of Multi-Gang Bank	Middle of Multi-Gang Bank
Sunnata PRO Dimmer (RRST-PRO-N)	Dimmable LED / CFL	250 W	200 W	150 W
Sunnata PRO Dimmer (RRST-PRO-N)	Incandescent / Halogen	500 W	400 W	300 W
Sunnata Hybrid Keypad (RRST-HN2B)	Dimmable LED / CFL	150 W	100 W	100 W
Sunnata Hybrid Keypad (RRST-HN2B)	Incandescent / Halogen	450 W	350 W	250 W

Critical Field Note: In the Mudroom 8-gang bank and upstairs 6-gang bank, all middle dimmers are derated to 150 W maximum LED capacity. Ensure no single LED zone exceeds 150 W total driver wattage.

Mounting Elevations & Casing Trim Clearance (E-101 / E-102)

Wall Keypads & Switches: Mounted at 4'-0" AFF (Above Finished Floor) to centerline of rough box.
Casing / Trim Clearance: Maintain minimum of 1-1/2" MIN. clear between rough wallbox edge and door/window casing trim.
Duplex Convenience Receptacles: Mounted at 18" AFF to centerline unless noted otherwise.
Accessibility: Dimmers in Mudroom and Mechanical Closets must remain readily accessible without removing drywall or permanent wall finishes.
